Dunlop DB01B DIME® CRY BABY® FROM HELL Wah Guitar Pedal
The Dimebag DB10B from Dunlop is a versatile wah pedal boasting a wide range of features for the stage.
The most versatile wah in our line up, this pedal was designed for players who need options on stage, featuring an extended sweep rang a 6-way frequency selector, a switchable boost, LEDs to indicate wah and boost status, and more.
This pedal can be powered by a 9-volt battery, a Dunlop ECB003 9-volt adapter, or the DC Brick™, Iso-Brick™, and Mini Iso-Brick™ power supplies (not included).
Specifications:
- Noise Floor (A-weighted): -102 dGV
- Maximum Gain At FC: 15 dBV
- Boost Range: 0.1 to 17 dB
- Bypass: Buffered
- Current Draw: 2.5 mA
- Power Supply: 9 volts DC
Impedance:
- Input Impedance: 1MΩ
- Output Impedance: <1 kΩ
Filter Center Frequency:
- Range 1 - Heel Down / Toe Down 440 Hz / 1.5 kHz to 2.2 kHz
- Range 2 - Heel Down / Toe Down 400 Hz / 1.3 kHz to 1.9 kHz
- Range 3 - Heel Down / Toe Down 375 Hz / 1.2 kHz to 1.8 kHz
- Range 4 - Heel Down / Toe Down 345 Hz / 1.0 kHz to 1.6 kHz
- Range 5 - Heel Down / Toe Down 295 Hz / 750 Hz to 1.4 kHz
- Range 6 - Heel Down / Toe Down 250 Hz / 1.2 kHz
Featuring a 6-way frequency selector, and LEDs to indicate the pedal's settings, the DB10B is as user friendly as it is efficient.
